TDA7294V Amplifier Integrated Circuits 100V 100W Dmos Audio Amplifier Speaker
Specifications
| Product Attribute | Attribute Value |
|---|---|
| TDA7294 | |
| Audio Amplifiers | |
| Class-AB | |
| 100 W | |
| 8 Ohms | |
| 0.01 % | |
| 40 V | |
| 10 V | |
| 0 C | |
| + 70 C | |
| Gain: | 80 dB |
| Height: | 10.7 mm |
| Ib - Input Bias Current: | 500 nA |
| Length: | 19.6 mm |
| Maximum Dual Supply Voltage: | +/- 40 V |
| Minimum Dual Supply Voltage: | +/- 10 V |
| Number of Channels: | 1 Channel |
| Operating Supply Current: | 65 mA |
| Operating Supply Voltage: | 50 V |
| Output Current: | 10 A |
| Output Signal Type: | Single |
| Pd - Power Dissipation: | 50000 mW |
| Vos - Input Offset Voltage: | + 0.5 V to - 0.5 V |
| Width: | 5 mm |
| Unit Weight: | 0.200003 oz |
Description
The TDA7294 is a monolithic integrated circuit in Multiwatt15 package, intended for use as audio class AB amplifier in Hi-Fi field applications (Home Stereo, self powered loudspeakers, Topclass TV). Thanks to the wide voltage range and to the high out current capability it is able to supply the highest power into both 4 Ω and 8 Ω loads even in presence of poor supply regulation, with high supply voltage rejection. The built in muting function with turn on delay simplifies the remote operation avoiding switching on-off noises.
Features
• Very high operating voltage range (± 40 V)
• DMOS power stage
• High output power (up to 100 W music power) • Muting/stand-by functions
• No switch on/off noise
• No boucherot cells
• Very low distortion
• Very low noise
• Short circuit protection
• Thermal shutdown
