    TK35N65W High Power Transistor 35A 650V

    Ask Lasest Price
    Brand Name : TOSHIBA
    Model Number : TK35N65W
    Price : Negotiate
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 5000pcs Per Mouth
    Delivery Time : 2-3work days
    • Product Details
    • Company Profile

    TK35N65W High Power Transistor 35A 650V

    TK35N65W High Power Transistor 35A 650V Switching Voltage 270W 115nC 80 MOhms Power Supply

    Applications

    Switching Voltage Regulators

    DTMOSIV Series MOSFETs

    Toshiba DTMOSIV MOSFETs use the state-of-the-art single epitaxial process, which provides a 30%

    reduction in RDS(on), a figure of merit (FOM) for MOSFETs, compared to its predecessor, DTMOSIII.

    This reduction in the RDS(on) makes it possible to house lower RDS(on) chips in the same packages.

    This helps to improve efficiency and reduce the size of power supplies. Toshiba DTMOSIV MOSFETs

    are ideal for use with switching regulators.

    Features

    (1) Fast reverse recovery time: trr = 130 ns (typ.)
    (2) Low drain-source on-resistance: RDS(ON) = 0.08 Ω (typ.) by used to Super Junction Structure : DTMOS
    (3) Easy to control Gate switching
    (4) Enhancement mode: Vth = 3 to 4.5 V (VDS = 10 V, ID = 2.1 mA)

    Specifications

    Product AttributeAttribute Value
    Product Category:MOSFET
    Si
    Through Hole
    TO-247-3
    N-Channel
    1 Channel
    650 V
    35 A
    80 mOhms
    - 30 V, + 30 V
    4.5 V
    115 nC
    - 55 C
    + 150 C
    270 W
    Tube
    Height:20.95 mm
    Length:15.94 mm
    Product Type:MOSFET
