Ry211024 General Purpose Relay 8a 24v Spdt Power Relay 5-Pin Group Conversion
Description
RY211024,Power Relays,24 VDC,8A,1 Form C,General Purpose Relays 24VDC SPDT 8A Flux proof
TE Connectivity's (TE) broad range of relays and contactors serve a variety of applications. The TE product line includes leading brands such as AGASTAT, AXICOM, CII, KILOVAC, OEG, P&B, PRODUCTS UNLIMITED, and SCHRACK. Switching capabilities range from dry circuit to 1600A, up to 70kV, and as high as 6GHz. Electromechanical, solid-state, and hybrid types range from SMT PC board-mount devices to large panel-mount units. TE's line of relays features expansive sets of options for enclosures, terminations, inputs, contact arrangements, and ratings. High-performance types are specifically designed to operate in rigorous environments (shock, vibration, temperature, altitude) such as those encountered in military and aerospace applications.
Features
• 1 pole 8A, 1 form C (CO) or 1 form A (NO) or 1 form B (NC)
contact
• Low component height 12.3mm
• 5kV/8mm coil-contact
• Reinforced insulation (protection class II)
• Pinnings: 3.2mm and 5mm
• Reflow-solderable version
• Especially suitable for resistive and inductive loads on form A
(NO) and form B (NC) contacts
• Plastic materials according to IEC 60335-1 (domestic appliances)
Applications
High-performance types are specifically designed to operate in rigorous environments (shock, vibration, temperature, altitude) such as those encountered in military and aerospace applications.
Date Sheet
| Product Attribute | Attribute Value |
|---|---|
| TE Connectivity | |
| Product Category: | General Purpose Relays |
| Power Relays | |
| 24 VDC | |
| 1 Form C (SPDT-NO, NC) | |
| 8 A | |
| Solder Pin | |
| Through Hole | |
| 400 VAC | |
| Non-Latching | |
| 2.35 kOhms | |
| Silver Nickel (AgNi) | |
| RYII | |
| 28.5 mm | |
| 10.1 mm | |
| 12.3 mm | |
| Tube | |
| Contact Form: | SPDT (1 Form C) |
| Power Consumption: | 245 mW |
| Factory Pack Quantity: | 20 |
| Subcategory: | Relays |
| Unit Weight: | 0.300287 oz |
