General Purpose Transistor IXTH200N10T 200A 100V 5.4 Rds 550W Dc-Dc Converters
Description
Single MOSFET Die,N-Channel Enhancement Mode Avalanche Rated, Low Qg
IXYS Gen1 Trench Gate Power MOSFETs are ideally suited for low voltage/ high current applications,
requiring an exceedingly low RDS(ON), enabling very low power dissipation. This, combined with
wide-ranging operating junction temperature, from -40°C to 175°C, make them suitable candidates
for automobile applications and other similar demanding applications in harsh environments.
Features
• IXYS advanced low Qg process
• Low gate charge and capacitances - easier to drive - faster switching
• International standard packages
• Low RDS (on)
• Rated for unclamped Inductive load switching (UIS) rated
• Molding epoxies meet UL 94 V-0 flammability classification
Applications
• DC-DC converters
• Battery chargers
• Switched-mode and resonant-mode power supplies
• DC choppers z AC motor control
• Temperature and lighting controls
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Product Category: | MOSFET |
| Si | |
| Through Hole | |
| TO-247-3 | |
| N-Channel | |
| 1 Channel | |
| 100 V | |
| 200 A | |
| 5.5 mOhms | |
| - 55 C | |
| + 175 C | |
| Enhancement | |
| HiPerFET | |
| IXTH200N10 | |
| Tube | |
| Brand: | IXYS |
| Configuration: | Single |
| Fall Time: | 34 ns |
| Height: | 21.46 mm |
| Length: | 16.26 mm |
