FGA25N120ANTD Power Switching IGBT 1200V 40A 310W TO3P High Speed Switching
Description
Employing NPT technology, Fairchild’s AND series of IGBTs provides low conduction and switching losses.
The AND series offers an solution for application such as induction heating (IH), motor control, general
purpose inverters and uninterruptible power supplies (UPS).
Features
• High speed switching
• Low saturation voltage : VCE(sat) = 2.5 V @ IC = 25A
• High input impedance
• CO-PAK, IGBT with FRD : trr = 235ns (typ.)
Applications
Induction Heating, UPS, AC & DC motor controls and general purpose
inverters.
Specifications
| Product Attribute | Attribute Value |
|---|---|
| onsemi | |
| Product Category: | Motor / Motion / Ignition Controllers & Drivers |
| - 55 C | |
| + 150 C | |
| Through Hole | |
| TO-3P-3 | |
| Tube | |
| Height: | 19.9 mm |
| Length: | 15.6 mm |
| Pd - Power Dissipation: | 310 W |
| Product Type: | Motor / Motion / Ignition Controllers & Drivers |
